Multiple User Kit includes:
- Dual Band Mobile Wireless Smart Technology Signal Booster w/ FME - Male Connector
- Interior slim antenna
- 12" Magnet Mount Antenna
**Note - this booster will work for Verizon, AT&T, Sprint and T-Mobile users to increase 3G and data card signal coverage.**
Increase your cell phone's signal with the Wilson Dual Band Mobile Wireless Cell Phone Signal Booster kit.
Designed for use in your car, truck, RV, or boat, this booster
significantly improves your cell phone's performance and signal
strength. It supports multiple cell phones and data cards
simultaneously, and works with all North American cell phone carriers*,
which include both Cellular (824-894 MHz) and PCS (1850-1990 MHz)
carrier frequency bands. You'll experience fewer dropped calls, faster
data rates, and clearer reception.
* Except Nextel, iDEN & 4G
-
Greatly reduces dropped calls, extends signal range, and increases data rates
-
No physical connection to your cell phone or data card
-
Allows multiple phones and cellular data cards to be used simultaneously
-
Oscillation (or interference) detection and automatic shutdown with auto reset
-
Overload protection circuit – protects cell towers from being overloaded
-
Amplifies signals both to and from the cell tower
-
Maximum 3000 milliwatts output power – More than 20 times the power of your cell phone
-
Antenna sold separately. See Options
-
Works on all generations of CDMA, TDMA, GSM, and 3G
-
Power control logic ensures maximum gain is within cellular standards
-
Extends battery life – Booster enables phone to work at reduced power
-
Passes TIA/EIA-98-E transmit tests for evaluating CDMA cellular phones
-
FCC and IC type accepted
Product Number
|
801201
|
|---|
|
Frequency
|
824-894 MHz / 1850-1990 MHz
|
|
Gain
|
50 dB / 50 dB
Automatic gain control
|
|
Max Uplink Power
|
2,800 mw / 2,300 mw
|
|
Max Downlink Power
|
+10 dBm
|
|
Noise Figure
|
3.5 dB nominal
|
|
Flatness
|
±4 dB
|
|
Power Requirements
|
6 V, 3 A max
|
|
Connectors
|
FME Male 50 ohm
|
|
Dimensions
|
4.5 x 3.5 x 1.25 (inches) / 11.43 x 8.9 x 3.2 (cm)
|
|
Weight
|
1.5 (lbs) / 0.7 (kg) |
|
|
|
 |
|
 |
|
