Single User Kit includes:
- SIGNALBOOST™ Dual Band Signal Booster w/ FME - Male Connector
- 12" Magnet Mount Antenna
- Cradle Plus w/Built in Antenna
**Note - this cradle will work for Verizon, AT&T, Sprint and T-Mobile users to increase 3G and data card signal coverage.**
Wilson’s affordable SIGNALBOOSTTM Cell Phone Signal Booster
is the perfect choice for the user looking to improve cellular signals
for a single cell phone or data card on the road or in a building. All
SIGNALBOOSTTM models work great in a car, boat, and building.
The included Ultra-Slim Antenna attaches to any phone or data card – no
equipment-specific adapter is required. The models are listed in the
specifications section with frequency information, and work with all
major North American cell phone carriers, which include both Cellular
(824-894 MHz) and PCS (1850-1990 MHz) carrier frequency bands.
-
Connects to ALL phones and data cards with an UltraSlim antenna - no
adapter required. Operates similar to direct connect signal boosters
-
Greatly reduces dropped calls, improves cell phone signal, and increase data rates
-
Easy to install and use
-
SIGNALBOOSTTM boosters do not cause oscillation
-
Overload protection circuit – protects cell towers from being overloaded
-
Amplifies signals both to and from the cell tower
-
Maximum 3000 milliwatts output power - More than 20 times the power of your cell phone
-
Increases data communication rates needed for 3G technologies
-
Works great in mobile, in-building and marine applications
-
Works on all generations of CDMA, TDMA and GSM
-
Extends battery life – Booster enables phone to work at reduced power
-
FCC and IC type accepted
-
The models are listed in the specifications section with frequency information
Product Number
|
811210
|
811710
International Use
|
811910
International Use
|
|---|
|
Frequency
|
824-894 MHz
1850-1990 MHz
|
890-960 MHz
1710-1880 MHz
|
890-960 MHz
1885-2200 MHz
|
|
Gain
|
30 dB / 30 dB
|
|
Max Uplink Power
|
2,700 mw / 1,070 mw
|
|
Max Downlink Power
|
+6 / +7 dBm
|
|
Noise Figure
|
3.5 dB nominal
|
|
Flatness
|
±2 dB
|
|
Power Requirements
|
12 V DC / 2 A max
|
|
Connectors
|
FME Male 50 ohm
|
|
Dimensions
|
5 x 3.5 x 1.2 (inches) / 12.7 x 8.9 x 3 (cm)
|
|
Weight
|
1.03 (lbs) / 0.468 (kg) |
|
|
|
 |
|
 |
|
